Gould Solenoid valve DST Major Rebuild Kit Teflon seat and 10-700 psi
DSTRK
      Gould Solenoid valve DST Major Rebuild Kit Teflon seat and 10-700 psi
      Gould Solenoid valve DST Major Rebuild Kit Teflon seat and 10-700 psi
      Gould solenoid Bronze valve DST solenoid valve Rebuild Kit to 300ºF

      The Gould DST major Rebuilt kit is for the D Series solenoid valves, Teflon seat with 10-700 psi

      Available in sizes ranging from 3/4" to 2" NPT threaded.

      Please note:  Typically ships out the same day but could take up to 1–2 days processing before shipping.

      Gould Solenoid Valves
      $272.34
      $306.00
      Save 11%
      Quantity :

      Free Shipping up to 5 lbs. Order before 10:30 on Friday and receive it between 6/11/26 and 6/16/26 with Free Shipping up to 5 lbs.

      Delivery Options
      Carrier Description Estimated Delivery
      Free Shipping up to 5 lbs. 5 to 6 days Transit

      6/11/26 - 6/16/26

      UPS Ground over 5 pounds 5 to 6 days Transit

      6/10/26 - 6/15/26

      UPS 3 bus. days Ships same or next day 3 bus-days Same day/next Order before 10:30 EST (Valve combo + 2)

      6/10/26 - 6/11/26

      UPS 2 bus. days Ships same day 2 bus-days, leaves WH same day if Order up to 10:30 EST

      6/9/26 - 6/10/26

      UPS Next Day - 1 business Day Ships same day except valve/act combo + 2 (Order before 10:30 EST)

      6/8/26 - 6/9/26

      Carrier: Free Shipping up to 5 lbs.

      Description: 5 to 6 days Transit

      Estimated delivery:
      6/11/26 - 6/16/26

      Carrier: UPS Ground over 5 pounds

      Description: 5 to 6 days Transit

      Estimated delivery:
      6/10/26 - 6/15/26

      Carrier: UPS 3 bus. days Ships same or next day

      Description: 3 bus-days Same day/next Order before 10:30 EST (Valve combo + 2)

      Estimated delivery:
      6/10/26 - 6/11/26

      Carrier: UPS 2 bus. days Ships same day

      Description: 2 bus-days, leaves WH same day if Order up to 10:30 EST

      Estimated delivery:
      6/9/26 - 6/10/26

      Carrier: UPS Next Day - 1 business Day

      Description: Ships same day except valve/act combo + 2 (Order before 10:30 EST)

      Estimated delivery:
      6/8/26 - 6/9/26

      X
      • Security -Security - Rest assured. Our site is encrypted and we do not store any payment information
      • Returns - Returns - Products are returnable if unused or defective. Need to call for an RMA authorization

      • The Gould DST Major Rebuild Kit replaces all internal components, including the piston, pilot assembly, spring, and seals, and can be installed without removing the valve from the line.

        Service Ratings
        • Pipe Sizes: 3/4”, 1”, 1¼”, 1½”, 2” NPT
        • Media: Liquid Service Only, Water & Aqueous Liquids, Oils (400SSU or 30SAE)
        • Pressure Range: 10-700psi
        • Rated Fluid Temperature Range: –40°F to +300°F
        Options
        Summary Specifications of Gould solenoid valve DST
        Size 3/4" 1" 1 1/4" 1 1/2" 2"
        Orifice 1" 1" 1 1/2" 1 1/2" 2"
        Cv Factor 6.3 11.5 18 28 50
        Weight (lbs) 1 1 2 4 5

        Please Note: Gould Solenoid Valves are designed for Industrial–Commercial applications. Residential/Consumer applications will void the warranty.

      • Gould Solenoid Valves
        DSTRK

        Data sheet

        Valve Size
        .75 ( 3/4") 1" 1.5 (1 1/2") 1.25 (1 1/4") 2"
        Valve Body Material
        Bronze
        Valve Connection
        NPT
        Valve PSI
        10-700
        Valve Seat
        Teflon
        Warranty
        1 year
        Valve Media
        Aqueous Liquids Oils (440SSU/30SAE) Water
        Solenoid Valve Temperature
        300°F
        Valve De-energized Position
        Normally Closed
