Chicago Valves Series 414 Class 600 Cast Steel Swing Check Valve, API 600, 2" - 4"
4146
The Chicago Valves Series 414 is an API 600 compliant, Class 600 flanged cast steel swing check valve engineered for heavy-duty industrial backflow prevention. Constructed with an ASTM A216 WCB body and ASTM A105 trim, it features a bolted cover for secure maintenance and an integral seat to eliminate leak paths behind the seat ring.
The Series 414 is NACE MR-0175 compliant for sour service and meets ASME B16.34 and B16.10 standards. Rated for 285 PSI at 100°F and temperatures up to 1,000°F, the Series 414 is tested to API 598 to ensure reliability in oil, gas, and steam applications. In addition to the Class 600 design, this series is also available in Class 150 and Class 300 configurations for higher-pressure service requirements.
Available in sizes from 2" to 4".
$466.31
$770.76
Save 39.5%
Security - Rest assured. Our site is encrypted and we do not store any payment information
Returns -
Products are returnable if unused or defective. Need to call for an RMA authorization
The Chicago Valves Series 414 is a high-performance industrial swing check valve designed for reliable unidirectional flow control. Built to API 600 standards, it utilizes a cast steel ASTM A216 WCB body to provide superior structural integrity in demanding process environments. The bolted cover design allows for straightforward internal inspection and maintenance, while the integral seat ensures a robust sealing surface for long-term service in steam, oil, and gas applications.
The Series 414 is available from 2" to 4" and is also offered in Class 150 and Class 300 configurations.
General Valve Specification
- Valve Type: Swing Check Valve
- Body Material: Cast Steel ASTM A216 WCB
- Disc Material: ASTM A105
- Seat Ring Material: ASTM A105 (Integral Seat)
- Seating Type: Metal-to-Metal (Precision Lapped)
- Operation: Automatic
- Cover Design: Bolted Cover
- Flow Function: Non-return / backflow prevention
- Service Type: Unidirectional flow service
- Pressure Rating: ASME Class 600 (1480 PSI @ 100°F / 38°C)
- Maximum Temperature: 1,000°F (538°C)
- End connections: Class 600 Flanged (RF)
- Country of Origin: China
Standards and Compliance
- API 600, API 598, ASME B16.34, NACE MR-0175, ASME B16.10, ASME B16.5, ASME B16.47 A&B, ASME B16.25
Pressure Class Availability
The Chicago valves 41 series Swing check Valve is available in the following ratings:
- Class 300: Series 414
- Class 300: Series 414
- Class 600: Series 414
Summary Specifications of Chicago Valves Series 414 Class 600
Size Part Number CV Weight (lbs) 2" 2041461 105.8 80 2 1/2" 2541461 123.2 93 3" 3041461 235.0 100 4" 4041461 391.1 185 - 4146
Data sheet
- Valve Type
- Swing Check
- Valve Size
- 2" 2.5 (2 1/2") 3" 4"
- Valve Temperature Range
- 1000 Max.
- Valve Body Material
- Cast Steel ASTM A216 WCB
- Valve Body Style
- RF (Raised Face)
- Valve Connection
- Class 600 Flanged
- Valve PSI
- 1480 (Max)
- Valve Configuration
- 2-Way
- Valve Seat
- Metal on Metal
- Warranty
- 1 year
- Valve Standards
- API 598 API 600 ASME B16.5 ASME B16.10 ASME B16.34 ASME B16.47 A&B NACE MR0175
The Chicago Valves Series 414 is an API 600 compliant, Class 600 flanged cast steel swing check valve engineered for heavy-duty industrial backflow prevention. Constructed with an ASTM A216 WCB body and ASTM A105 trim, it features a bolted cover for secure maintenance and an integral seat to eliminate leak paths behind the seat ring.
The Series 414 is NACE MR-0175 compliant for sour service and meets ASME B16.34 and B16.10 standards. Rated for 285 PSI at 100°F and temperatures up to 1,000°F, the Series 414 is tested to API 598 to ensure reliability in oil, gas, and steam applications. In addition to the Class 600 design, this series is also available in Class 150 and Class 300 configurations for higher-pressure service requirements.
Available in sizes from 2" to 4".
